Sony Mobile XAV-AX3200 6.95" Bluetooth Media Receiver with Apple CarPlay and Android Auto

Regular price $278.00
Sale price $278.00 Regular price
$349.99 Save $71.99 (21%)
OR

Limited time offer! Sale ends 12/8/2024.
In Stock & Ready to Ship
Free Shipping Get it between Thu, Dec 5 – Thu, Dec 12

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: XAVAX3200 | UPC: 027242922327

Specifications

What's In The Box

Product Information

Model: XAVAX3200 | UPC: 027242922327

Full smartphone integration and enhanced connectivity

Enjoy smartphone connectivity including screen mirroring with WebLink™. An anti-glare 6.95" (17.6cm) diagonal touchscreen wakes up right after turning on the ignition and gives you intuitive control over music, communications, and more. Newly added A/V connectivity allows you to hook up external audio or visual source device.

Features:

  • Mirror and control selected smartphone apps with WebLink Cast
  • Anti-glare touchscreen with quick boot
  • EXTRA BASS™ adds low-end power
  • A/V input for an external audio and visual source device
  • Rear-view camera ready for safe reversing

Siri with Apple CarPlay

Easily access the iPhone features you know and love, just by talking to Siri. Music, maps, phone calls, and messages are all under your control.

Voice Control with Android Auto

Use voice commands to dictate messages, take phone calls, or get help from Google Maps. You can even control music playback, just by talking.

WebLink™ Cast compatible

WebLink™ is a lightweight app delivery platform designed especially for in-vehicle use. Using the Android or iOS device connection, it is now possible to mirror your smartphone screen right on the car audio display—for reliable, responsive infotainment anytime on the road.

WebLink® Cast compatible

WebLink® is a lightweight app delivery platform designed especially for in-vehicle use. Using the Android or iOS device connection, it is now possible to mirror your smartphone screen right on the car audio display—for reliable, responsive infotainment anytime on the road.

Anti-glare clear responsive touchscreen

The anti-glare 6.95" (17.6cm) touchscreen gives you intuitive control over music playback, making phone calls, and more.

Easy installation with a compact rear chassis

Despite its double-DIN display, the rear chassis is far smaller than conventional double-DIN units. This makes for much easier installation and leaves plenty of room for cabling and other accessories in the space behind the display.

A/V input connectivity

A composite video and stereo audio input terminal enable connection with an external source device.

Build your own sound system

With the three pre-outs, you can add components of your choice, like extra amplifiers or subwoofers.

Rear camera ready for easy reversing

If you've got a rear camera installed, you can use it to help you park. Whenever you tap the rear camera icon or put your vehicle in reverse, the video feed instantly comes up on the screen. Customizable guidelines help you to back in smoothly and safely.

Bluetooth® wireless technology

Make hands-free calls and stream wireless audio from your smartphone with Bluetooth®.

Powerful, clear amplification

Advanced signal processing from the 4 x 55 W Dynamic Reality Amp 2 removes interference, so music sounds clear and detailed, even when you crank up the volume.

Dynamic Stage Organiser creates virtual speakers on your dashboard

Sound waves are directional, especially in the higher frequencies—so if your speakers are positioned low in your doors, high-frequency sounds are often lost, reducing clarity and instrument separation. Dynamic Stage Organiser uses digital signal processing to lift the sound, improving stereo positioning so music sounds like it's coming from right in front of you.

FLAC compatible

FLAC compatibility lets you play lossless audio files, so you can enjoy every detail of the music.

SiriusXM® Radio ready

Connect your SiriusXM® Radio satellite tuner (not supplied) to enjoy commercial-free music, sports, news, and entertainment.

Quick Wake-up

With the Quick Wake-up feature, you're ready to go, right after turning the ignition.

Anti-glare clear responsive touchscreen

The anti-glare 6.95" (17.6cm) touchscreen gives you intuitive control over music playback, making phone calls, and more.

Specifications

  • Product Basic Info
    • Model Code: XAV-AX3200
    • Spec: UC
  • Display
    • Screen Size: 6.95"
    • Touch Panel: Resistive + AG
  • Sound
    • Output Power: 55W
    • EXTRA BASS: Yes (Off/1/2)
    • Graphic Equalizer: 10Band Graphic Equalizer
    • DSO: Yes
    • Time Alignment: No
  • Expandability
    • Pre Out: 3 Pre (Front / Rear / Sub x 1)
    • High Voltage Pre Out: No
    • AUX input (Stereo Mini-Jack): No
    • AUX/Video input (RCA): Yes (Mini-Jack)
    • Rear View Camera Input: Yes
    • Video Out: No
    • USB: Yes (Rear x1)
    • Bluetooth: Yes
    • Extension Connector: No
    • Sirius XM Ready: Yes
    • DAB: No
  • Smartphone Linkage
    • Apple CarPlay: Yes
    • Android Auto: Yes
    • WebLink: Yes (WebLink CAST)
    • Voice Command (Smartphone Function) Activate: Yes (Only CPAA)
  • General Feature
    • DVD/CD Playback: No
    • Sub Woofer Out initial: Normal
    • Sub Woofer adjust: Yes
    • Sub Woofer adjust initial: 0dB
    • Sub Woofer Phase: Yes (Normal/Reverse)
    • Balance initial: Center
    • Fader initial: Center
    • High Pass Filter initial: OFF
    • Low Pass Filter initial: 100Hz
    • ATT initial: OFF
    • DVD LEVEL Adjust initial: No
    • Zone x Zone: No
    • PICTURE EQ initial: Dynamic
    • Aspect Ratio Initial: Full
    • USB High Charge: Yes / 1.5A
    • Firmware upgradability: Yes
    • Tag Indication: Yes (Except Flac and WAV)
    • HD Radio embedded: No
  • Tuner Feature
    • Preset: FM18/AM12
    • Auto Memory: BTM
    • FM 50k/100k/200k change: No
    • AM 9k/10k change: No
    • RDS/EON: Yes (RBDS)
    • AF: No
    • TA: No
  • USB Control Feature
    • List: Yes
    • Repeat: Yes
    • Repeat Initial: All
    • Shuffle: Yes
    • Shuffle initial: Off
    • Pause: Yes
    • ID3 Tag Indication (Version_ Title/Artist/Album): Yes
    • CUE/REV: Yes (Video: lock search)
    • Max LayerNo./FolderNo./FileNo.: 8/1000/20000
    • MP3 playback: Yes
    • WMA playback: Yes
    • AAC playback: Yes
    • WAV playback: Yes
    • JPEG playback: No
    • MPEG-4 playback: Yes
    • H.264 playback: Yes
    • Divx playback: No
    • Xvid playback: Yes
    • PICTURE EQ: Yes
  • BT Spec.
    • Version: Bluetooth Version 3.0
    • EDR: -
  • Profile
    • HFP: Yes (1.6)
    • HSP: No
    • A2DP: Yes (1.3)
    • OPP: No
    • DUN: No
    • SPP: No
    • AVRCP: Yes (1.3)
    • AVRCP(MTE): No
    • PBAP: Yes (1.1)
    • SAP: No
    • VDP: No
    • BIP: No
  • Bluetooth Feature
    • Speed dial: Yes (6 memories)
    • Recent calls (No.of): Yes
    • Last dialed call: Yes (select from the dialed call history)
    • Phonebook(Built-in): No
    • Phonebook code: UTF8
    • Phonebook Access via PBAP: Yes
    • Alphabetical Phonebook Sorting (Built-in): No
    • Alphabetical Phonebook Sorting (PBAP): Yes
    • Phone data password lock: No
    • Connection status (maximum No.): [1HFP/PBAP+1Audio]
    • Display for connecting list: No
    • Any Key Answer: No
    • Auto Answer: No
    • RF ON/OFF: Yes
    • DTMF: No
    • Internal ringtone: 1 (2016 Sony Mobile Ringtone)
    • Noise canceller: Yes
    • Echo canceller: Yes
    • Ring alert select: No
    • Ring volume level control: Yes
    • Call volume level control: Yes
    • MIC GAIN Adjustment: Low/Mid/High
    • TEL out channel: Front / Rear / All
    • Voice Dial Activation: No
    • Built-in microphone: No
    • External microphone: Supplied
    • Battery remainder indication: Yes
    • Signal strength indication: Ye
  • Bluetooth Audio Feature
    • Audio Codec: SBC / AAC
    • PAUSE: Yes
    • CUE/REV: Yes
    • TRACK +/- : Yes
    • Group (Folder) +/- : Yes
    • Audio Level Adjustment: Yes (-6dB to +6dB)
    • Audio Level Adjustment initial: 0dB
    • Repeat Control (Audio Device side): Yes
    • Shuffle Control (Audio Device side): Yes
    • Meta Data Indication: Yes
  • Other features
    • Device Name: XAV-AX3200
  • Panel Design
    • Panel Surface Finish Color: Black
    • key illumination: Yes (White)
    • Panel Detachability: No
  • Monitor(AVC)
    • LCD Type: TFT Active Matrix
    • Screen Aspect: 16:9
    • Resolution(DOT): 800 × 480
    • Dimmer: Yes
    • Dimmer Method: Auto/Manual select
    • Screen Mode: Yes: TYpe1 to 4
    • Color System: NTSC/PAL
    • Color System Auto switch: Yes
    • Contrast Ratio: 600
    • Viewing Angle (Contrast Ratio 10-1): 70/70/60/65 (L/R/U/D)
    • Response Time (black to white/white to black): Tr+Tf= 30 mS
    • Brightness: 800 cd/m2
    • Dimmer Adjust: Yes
    • Screen Diagonal: 6.95"
    • Screen Size(WxH mm): 156.6 x 81.6 (mm)
  • Display Panel(MDP and AVC)
    • Dimmer Area: Display Monitor and Key
    • Monitor off mode: Yes
    • Menu: English/Spanish/French/German/Italian/Russian/Portuguese/Thai/Simplified Chinese/Traditional Chinese/Korean/Arabic/Indonesian
  • Multi-Language
    • Caution: English/Spanish/French/German/Italian/Russian/Portuguese/Thai/Simplified Chinese/Traditional Chinese/Korean/Arabic/Indonesian
    • Menu/Caution Initial: English
    • ID3 Tag: English/Spanish/French/German/Italian/Russian/Portuguese/Thai/Simplified Chinese/Traditional Chinese/Korean/Arabic/Indonesian
    • Source List: Yes
  • User Interface
    • Clock: 12H
    • Rotary commander ( )-Option: No
    • Remote Commander ( )-Option: RM-X170
    • Parking Control: Yes
    • Wallpaper Initial: Blue
    • Wallpaper customization: Yes
    • List Function: Yes
    • Aspect Ratio Select: Yes
    • Rear View Camera-In Marker Setting: Yes
    • Demo Mode: Yes
    • Version: USB2.0 (High speed)
  • USB Specification
    • USB Mass Storage Device: Yes
  • USB Capability
    • USB Media Transfer Protocol: No
    • USB Hub: No
    • File System: exFAT, FAT12/16/32
    • Connection-enabled device list: WEB Support
    • Repeat: TRACK/FOLDER/DRIVE
  • USB Mass Storage Device Control Feature
    • Shuffle: OFF/FOLDER/DEVICE
    • Pause: Yes
    • Resume Play: Yes
    • Plug and Play: No
    • Audio Codec: PCM/MP3/WMA/AAC/FLAC
    • Audio Playable File Extension: wav/.mp3/.wma/.m4a/.flac
    • Video Codec: MPEG4-SP/AVC(H.264 Baseline)/WMV/MKV/XviD
    • Video Playable File Extension: .mp4/.wmv/.mkv
    • MTP: No
    • FM(Tuning range(MHz)/step(kHz)/de-emphasis(mus))65-74/30/50(or75)_87.5-108/50/50: No
  • Tuner
    • FM(Tuning range(MHz)/step(kHz)/de-emphasis(mus)) 87.5-108/50/50: No
    • FM(Tuning range(MHz)/step(kHz)/de-emphasis(mus)) 87.5-107.9/200/75: Yes
    • FM(Tuning range(MHz)/step(kHz)/de-emphasis(mus)) 87.5-107.9/100/75: No
    • MW(Tuning range(kHz)/step(kHz)) 531-1602/9: No
    • MW(Tuning range(kHz)/step(kHz)) 530-1710/10: Yes
    • LW(Tuning range(kHz)/step(kHz)) 153-279/seek 9 manual 1: No
    • SW(Tuning range(kHz)/step(kHz)) 5950-6205/5: No
    • FM-Tuning range(MHz): 87.5-107.9
    • MW-Tuning range(kHz): 530-1710
    • LW-Tuning range(kHz): No
    • Accessibility: Closed Caption / TTS: No support
  • General
    • Preout output level(V): 2Vrms
    • Maximum output power (4ohms_ 1kHz_ 16V)(W): 55W
    • CTA2006 output power: 20W
    • CTA2006 S/N: 80dBA
    • Speaker impedance(ohms): 4-8Ω
    • Connector type: 16P
    • ANT connector: JASO
    • Dimensions (WxHxD)(mm): 178 x 100 x 139
    • Mounting dimensions (WxHxD)(mm): 182 x 111 x 120
    • Weight(kg): 1.0
  • Accessory
    • Fitting Frame: No
    • Collar: No
    • Warranty card: Yes (NA for 1 year)
    • ISO connector: No
    • MRP Sticker for 'IN' version(India): No
    • Maruti-CDO Stickers (MGA/Packing List/PartsNo.): No
    • Maruti Connector Cable: No
    • Remote Commander Remote Control: RM-170
    • Steering Remote Control cable: RC-SR1
    • Bluetooth microphone: Yes (Wired)

What's In The Box

  • XAV-AX3200 6.95" Media Receiver with WebLink Cast
  • Remote Commander Remote Control
  • Parts for installation and connections
  • Operating Instructions
  • Warranty Card
